Combined Karaoke Power Amplifier

H-2
H-2
H-2
H-2
H-2

Independently developed 3×DSP digital processing technology

  • Independently developed 3×DSP digital processing technology, LED blue screen display, large knob with translucent blue light cup, exuding elegance, simple operation, clear at a glance. Music and microphone tone adjusted via a 7-band equalizer, with adjustable low-cut frequency point.


Main Features

  • Output power: Stereo 8Ω 350W+350W
  • Frequency response: 20Hz-20kHz, ±0.5dB
  • Output interfaces: Binding post and Speakon
  • Input sensitivity: 0.77V
  • Signal-to-noise ratio: ≥100dB
  • Total harmonic distortion: ≤0.035%
  • Net weight: 14.95kg
  • Dimensions: 485mm × 100mm × 390mm

Product Description


Independently developed 3×DSP digital processing technology
LED blue screen display, large knob with translucent blue light cup, exuding elegance and offering simple operation with clear visibility
Seven-band equalizer adjustment for music and microphone tone, with adjustable low-cut frequency point
Independently developed professional anti-feedback (anti-howling) technology
Startup volume settings and maximum volume lock function for music, microphone, and effects
Startup music, microphone, and effects mode presets
USB interactive tuning software control interface
The DSP series dual-effect karaoke amplifier provides the perfect solution for KTV systems. It exclusively adopts digitally controlled analog audio processing circuits, allowing singers to experience an unprecedented new level of karaoke enjoyment!
Professional commercial-grade integrated amplifier with ultra-high stability, ample power, and a sense of dynamics no less than that of professional power amplifiers
Dual DSP stacked effect processing circuit for effortless and natural singing, with more delicate spatial sensation
Equipped with load-limiting circuits and fully complementary symmetrical circuits to ensure speaker system protection during overloads.
Powerful output with minimal distortion, high signal-to-noise ratio, and perfect sound quality.
Dual heatsink and fan structure design for optimal cooling performance
Both front and rear panels feature microphone output ports, ensuring convenience for both aesthetic appeal and engineering installation.
Professional PCB layout for clearer and more harmonious circuitry, delivering a more visually perfect overall design.
Model: H-2
Output Power: Stereo 8Ω 350W+350W
Frequency Response: 20Hz-20kHz, ±1.5dB
Output Connectors: Binding and Speakon
Input Sensitivity: 0.77V
Balanced Input Impedance: 20kΩ/Balanced, 10kΩ/Unbalanced
Signal-to-Noise Ratio: ≥100dB
Total Harmonic Distortion: ≤0.035%
Separation at Rated Power (8Ω, 1kHz): >65 dB
Slew Rate: 15V/μS
Protection: Soft Start, Short Circuit, Limiter, DC Fault, AC Line Fuse, Thermal Cut
Cooling System: Dual Fans
Power Supply: AC: 220-230V, 50Hz/60Hz
Net Weight: 14.95 kg
Dimensions: 485mm × 100mm × 390mm
