APO-206

Ultra-compact two-way array point source system

APO-206
APO-206
APO-206
APO-206
APO-206
APO-206
APO-206
APO-206

Dual 6.5" neodymium magnet ultra-low distortion cone driver unit

  • The APO206 is an ultra-compact dual 6.5" two-way array point source system. It combines the versatility of point source systems with the "arrayability" of line array systems, creating a unique product category in the field of sound reinforcement for small to medium-sized venues.


Main Features

  • Rated Power: 500W (AES)
  • Peak Power: 2000W (AES)
  • Input Connectors: 2*NeutrikTM 2+2-
  • Sensitivity: 97dB
  • Maximum SPL: 131dB
  • Nominal Impedance: 12Ω
  • Dispersion: 90° X 60°
  • Net Weight: 12.2Kg
  • Dimensions: 518mm*200mm*358mm (W*D*H)

Product Description

The APO206 is an ultra-compact dual 6.5" two-way array point source system that combines the versatility of point source systems with the "arrayability" of line array systems, creating a unique product category in the field of small to medium-sized venue sound reinforcement. Leveraging the latest technologies from Audio in driver units and system design, the APO206 delivers nearly twice the rated power output of other speaker systems. Its emergence has allowed audio system designers to experience the dream of high-fidelity sound with a wide dynamic range, incredible flexibility, and adjustable horizontal directivity.

Technical Specifications


Type: Two-way Array Point Source System
Frequency Response: 40Hz-20kHz
Power: 500W
Peak Power: 2000W
Impedance: 12Ω
Dispersion: 90° X 60°
Sensitivity: 95dB
Maximum SPL: 129dB
Crossover Frequency: 1.6kHz Built-in Crossover
Input Connectors: 2*NeutrikTM 2+2-
Low Frequency: 12" Woofer Component with European Imported Bass Unit, 3"(75mm) Voice Coil, Rated Power: 300W (AES)
High Frequency: 1" Throat, European Imported Compression Driver Unit, 1.75" (44mm) Voice Coil, Rated Power: 50W (AES)
Enclosure Material: 15mm Marine-grade Birch Plywood
Enclosure Finish: Black Polyurea Paint
Net Weight: 23.5Kg
Dimensions: 360mm*605mm*378mm (W*D*H)
