Product Description
2" Color LCD Smart Display Window: Real-time display of current voltage, date/time, and channel switch status;
Timed power on/off function with built-in clock chip, allowing automatic operation based on date/time settings, eliminating manual intervention for simplified device management;
8-channel output, each equipped with a filter to eliminate current impurities. Independent delay settings (0~999S) for each channel's on/off timing;
Save/recall 10 sets of device switch scene data for easy and convenient scene management;
Wide voltage range (90V-250V) switching power supply design, featuring under-voltage/over-voltage detection and alarm functions, ensuring reliable protection for your devices. Total power capacity: 6000W, max 2000W per channel;
Supports multi-device cascading control with automatic detection and configuration of cascading status. Includes trigger functionality;
Equipped with RS232 serial port and TCP/IP network port, compatible with external central control devices (selectable baud rate); enables remote centralized control. Each device has a unique ID for detection and configuration;
Panel Lock function to prevent accidental manual operation;
Suitable for: Large multimedia conference halls, multifunctional venues, training centers, multimedia classrooms, high-end villas, smart homes, etc.
2" color LCD smart display window, which shows real-time voltage, date and time, and channel switch status;
Timed power on/off function with a built-in clock chip, allowing automatic operation based on date and time settings without manual intervention, making device management simpler;
8-channel output, each equipped with a filter to eliminate current impurities. Each channel's delayed turn-on and turn-off time can be freely set (range: 0~999s);
Save/call 10 sets of device switch scene data for simple and convenient scene management;
Wide-voltage (90V-250V) switching power supply design, featuring under-voltage and over-voltage detection and alarm functions, providing reliable protection for your equipment. Total power: 6000W, maximum single-channel power: 2000W;
Supports cascaded control of multiple devices, with automatic detection and configuration of cascading status. Equipped with trigger function;
Configured with RS232 serial port and TCP/IP network port, supporting external central control devices with selectable baud rates;
Enables remote centralized control, with each device featuring built-in ID detection and configuration;
Supports panel Lock function to prevent accidental manual operation.
