L-450M

Two-channel power amplifier

L-450M
L-450M
L-450M
L-450M

The 450W power output features high energy efficiency, low distortion, and ultra-lightweight characteristics, making it cost-effective.

  • The L-450M is a 2-channel digital circuit processing power amplifier capable of amplifying weak electrical signals from a signal source to drive speakers and produce sound.


Main Features

  • Output Power: Stereo 8Ω: 2X450W | Stereo 4Ω: 2X675W | Bridged 8Ω: 1350W
  • Frequency Response: 20Hz–20kHz (±0.5dB)
  • Output Connectors: Binding Post and Speakon
  • Input Sensitivity: 0.77V
  • Signal-to-Noise Ratio: ≥95dB
  • THD (Total Harmonic Distortion): ≤0.03%
  • Net Weight: 12.7kg
  • Dimensions: 482mm × 344mm × 88mm (W × D × H)

Product Description

The L-450M is a 2-channel digital circuit processing power amplifier capable of amplifying weak electrical signals from the signal source to drive speakers and produce sound. With a maximum output power of up to 900W, the massive power output ensures the greatest power headroom, enabling 5S speakers to deliver superior sound quality. The L-450M power amplification circuit adopts a true Class I circuit design, providing more precise sound while maintaining substantial power headroom, allowing the speakers to perform at their best. A high-quality audio system relies heavily on the indispensable role of the amplifier.
Model: L-450M
Output Power: Stereo 8Ω: 2X450W | Stereo 4Ω: 2X675W | Bridged 8Ω: 1350W
Frequency Response: 20Hz-20kHz, ±0.5dB
Output Connectors: Binding Post and Speakon
Input Sensitivity: 0.77V
Balanced Input Impedance: 20kΩ (Balanced) | 10kΩ (Unbalanced)
Signal-to-Noise Ratio: ≥95dB
Total Harmonic Distortion: ≤0.03%
Channel Separation at Rated Power (8Ω, 1kHz): >70dB
Slew Rate: 15V/μS
Protection: Soft Start, Short Circuit, Limiter, DC Fault, AC Line Fuse, Thermal Cutoff
Cooling System: Dual Fan
Power Supply: AC: 220-230V, 50Hz/60Hz
Net Weight: 12.7 kg
Dimensions (W×D×H): 482mm × 344mm × 88mm
