FS-08

Single 8“ two-way multi-purpose full-range waterproof Loundspeaker

FS-08
FS-08
FS-08
FS-08
FS-08
FS-08
FS-08
FS-08

8" high-power ultra-low distortion neodymium bass driver

  • The FS series is a compact, waterproof full-range loudspeaker system that is originally imported and integrates the best drive units with waveguide technology.


Main Features

  • Rated Power: 250W (AES)
  • Peak Power: 1000W (AES)
  • Input Connection: 2*4-pin aviation waterproof socket (1+2-)
  • Sensitivity: 94dB
  • Maximum Sound Pressure Level: 123dB
  • Nominal Impedance: 8 ohms
  • Dispersion Angle: 90° × 60°
  • Net Weight: 10Kg
  • Enclosure Dimensions: 246mm × 451mm × 240mm (W × H × D)

Product Description

The FS series is a compact, waterproof full-range speaker system that is originally imported and integrates the best drive units with waveguide technology. Equipped with a square, rotatable aluminum horn, it provides exceptional directional control free from internal diffraction and resonance. Surpassing traditional horn theory, the aluminum horn significantly reduces resonance, thereby improving sound quality. The FS series speaker system features high-end neodymium tweeters with an annular diaphragm design that minimizes intermodulation distortion. The neodymium driver includes a triple-layer copper flat-wire voice coil, ensuring ultra-low distortion and increased power handling. The ultra-low distortion neodymium woofer incorporates a triple-layer voice coil and a high-flux linear magnet, further ensuring minimal distortion and enhanced power handling. The integrated specialized passive crossover ensures linear frequency and phase response for optimal sound quality. Designed for fixed installations in outdoor performances, large water parks, amusement parks, northern regions, and other venues.

Technical Specifications


Type: 2-Way Multi-Purpose Full-Range Waterproof Speaker System
Frequency Response: 56Hz-20kHz
Power: 250W
Peak Power: 1000W
Impedance:
Dispersion Angle: 90° X 60°
Sensitivity: 94dB
Maximum SPL: 123dB
Crossover Point: 1.8kHz Built-in Crossover
Input Connector: 2*4-Pin Aviation Waterproof Socket (1+2-)
Low Frequency: 8" Woofer with European-imported Neodymium Magnet, 2" (50mm) Voice Coil, Rated Power: 250W (AES)
High Frequency: 1" Throat, European-imported Neodymium Compression Driver, 1.5" (38mm) Voice Coil, Rated Power: 50W (AES)
Enclosure Material: 15mm Marine-Grade Birch Plywood
Enclosure Finish: Black Polyurea Paint & Internal Epoxy Resin Treatment
Net Weight: 10Kg
Dimensions: 246mm*451mm*240mm (W*H*D)
