FS-210

Dual 10" full-range waterproof line array speaker

FS-210
FS-210
FS-210
FS-210
FS-210
FS-210
FS-210
FS-210

10" high-power ultra-low distortion neodymium bass driver

  • The FS series is a compact, waterproof full-range loudspeaker system that is originally imported and integrates the best drive units with waveguide technology.


Main Features

  • Type: LF/2×10″ + HF/1×1.5″ throat
  • Frequency Response: LF/60Hz–4000Hz, HF/500Hz–20000Hz
  • Power (AES): LF/400W (AES) per unit, HF/70W (AES) per unit
  • Impedance: 16Ω
  • Dispersion: 90°×10°
  • Maximum SPL: 139dB
  • Sensitivity: LF/97dB (1W & 1M), HF/109dB (1W & 1M)
  • Weight: 34.15kg
  • Enclosure Dimensions: 870mm × 303mm × 400mm (W × H × D)

Product Description

The FS series is a compact, waterproof full-range speaker system that is originally imported and integrates the best drive units with waveguide technology. Equipped with a square, rotatable aluminum horn, it provides exceptional directional control free from internal diffraction and resonance. Surpassing traditional horn theory, the aluminum horn significantly reduces resonance, thereby improving sound quality. The FS series speaker system features high-end neodymium tweeters with an annular diaphragm design that minimizes intermodulation distortion. The neodymium driver includes a triple-layer copper flat-wire voice coil, ensuring ultra-low distortion and increased power handling. The ultra-low distortion neodymium woofer incorporates a triple-layer voice coil and a high-flux linear magnet, further ensuring minimal distortion and enhanced power handling. The integrated specialized passive crossover ensures linear frequency and phase response for optimal sound quality. Designed for fixed installations in outdoor performances, large water parks, amusement parks, northern regions, and other venues.

Technical Specifications


Type: LF/2*10〞+HF/1*1.5" Throat
Frequency Response: LF/60Hz-4000Hz, HF/500Hz-20000Hz
Power: LF/400W (AES) per unit, HF/70W (AES) per unit
Impedance: 16Ω
Dispersion Angle: 90° × 10°
Sensitivity: LF/97dB (1W & 1M), HF/109dB (1W & 1M)
Maximum SPL: 139dB
Crossover Point: External Crossover
Input Connector: 10-pin Waterproof Professional Plug
Enclosure Connection: Aluminum Profile 210
Enclosure Material: 15mm Marine-grade Birch Plywood
Enclosure Finish: Black Polyurea Paint, Internal Epoxy Resin Treatment
Speaker Mounting Hardware: FS-210 Compatible Accessories
Line Array Pin Component: Φ10mm × 50mm
Enclosure Cover: --
Net Weight: 34.15kg
Dimensions: 870mm × 303mm × 400mm (W × H × D)
