G12

Single 12" two-way compact versatile full-range loundspeaker

G12
G12
G12
G12
G12
G12
G12
G12

12" high-power ultra-low distortion bass

  • The AUDIO G-12 features a high-quality 1" patented annular high-frequency driver unit and an ultra-low distortion neodymium low-frequency driver unit equipped with a triple demodulation ring 3" voice coil.


Main Features

  • Rated Power: 600W (AES)
  • Peak Power: 2400W (AES)
  • Input Connectors: 2*NeutrikTM 1+1-
  • Sensitivity: 98dB
  • Maximum SPL: 132dB
  • Nominal Impedance: 8 Ohms
  • Coverage Angle: 90° × 60°
  • Net Weight: 17Kg
  • Dimensions: 348mm × 630mm × 320mm (W × H × D)

Product Description

The G-12 features a high-quality 1" patented annular high-frequency driver unit and an ultra-low distortion neodymium low-frequency driver unit equipped with a triple demodulation ring 3" voice coil.
The G12 has a rated nominal power of 600W, incorporating one ultra-low distortion 12" neodymium low-frequency driver unit and one 1" neodymium compression driver unit coupled to a 90° × 60° rotatable elliptical waveguide. However, this is no ordinary compression driver unit: the high-frequency driver unit of the G12 incorporates Audio's unique technology, which significantly reduces intermodulation distortion (IMD), delivering exceptionally clear and transparent sound performance.

Technical Specifications


Type: 2-Way Full-Range Multi-Purpose Loudspeaker System
Frequency Response: 60Hz-20kHz (-6dB)
Power: 600W
Peak Power: 2400W
Impedance:
Dispersion Angle: 90° X 60°
Sensitivity: 98dB
Maximum SPL: 132dB
Crossover Frequency: 1.3kHz Built-in Crossover
Input Connector: 2*NeutrikTM  1+1-
Low Frequency: 12" Woofer with Aerospace-Grade Neodymium Magnet, 3" (75mm) Voice Coil, Rated Power: 600W (AES)
High Frequency: 1" Throat, Aerospace-Grade Neodymium Driver, 1.75" (44mm) Voice Coil, Rated Power: 80W (AES)
Cabinet Material: 15mm Marine-Grade Birch Plywood
Cabinet Finish: Black Polyurea Paint
Net Weight: 17Kg
Dimensions: 348mm*630mm*320mm (W*H*D)
