Product Description
The N-5 is suitable for various types of collective activities or exhibition venue sound reinforcement, DJ monitoring, small entertainment venue sound reinforcement, or as stage monitoring or front-fill for live performances. In theaters, it is ideal for use as under-balcony fill.
The high-frequency driver of the N-5 features an ultra-light 1.75-inch annular diaphragm, delivering exceptional transient response with extremely high efficiency across a frequency range of 1 kHz to 20 kHz. This innovative transducer design produces a coherent 100° wavefront from a point source, offering excellent coverage control and clear, transparent high-fidelity sound. Additionally, it ensures perfectly time-aligned, uniform sound coverage in coordination with other components.
Technical Specifications
| Type: | 2-way Full-range Multi-purpose Coaxial Loudspeaker System |
| Frequency Response: | 80Hz–20kHz |
| Power: | 320W |
| Peak Power: | 1280W |
| Impedance: | 8Ω |
| Dispersion Angle: | 100° conical |
| Sensitivity: | 94dB |
| Maximum SPL: | 124dB |
| Crossover Frequency: | 1.5kHz (built-in crossover) |
| Input Connector: | 2*NeutrikTM NL4MP 1+1- |
| Low-frequency Driver: | 5"*2 aerospace-grade ferrite woofer, 1.5" (38mm) voice coil, rated power: 300W (AES) |
| High-frequency Driver: | 1" throat, aerospace-grade ferrite compression driver, 1.75" (44mm) voice coil, rated power: 80W (AES) |
| Enclosure Material: | 12+15mm Russian birch plywood |
| Enclosure Finish: | Black polyurea paint |
| Net Weight: | 6.0kg |
| Dimensions: | 155mm*350mm*205mm (W*H*D) |
