Product Description
This device is based on DSP technology, with much more functions.lt comeswith 2ins 4 outs, 2ins 6 outs, 4ins6 outs, 4ins 8 outs can be flexible for severalx-over mode.Especially for the live sound.
-
96KHz sampling frequency, 24 bitAD/DA converter, 32 bit DSP processor.USB and LAN interfaces are provided to connect PC, and the third-party controlsystem can be controlled through RS485 interface.Up to 250 machines canbe connected, and the control distance is not more than 1500 meters.USB/RS232/RS485 remote control(perfect matching controller) connectorsare available provided to be withPC
-
With 12 groups users data.
-
Panellock function.
-
Each input channels are with 31 bands GEQ and 10 bands PEQ, output channelsare with 10 bands PEQ
-
Highpass and Lowpass filters: Linkwitz-Riley/Bessel/Butterworth(12dB/oct、18dB/oct、24dB/oct、48dB/oct).
-
Each input/output channels with delay, phase and mute. (Max delay: 1000msEach output channels with gain, limiter and input signal, and choose severaloutputto set parameter at the same time.
-
lR and FlR algorithms for frequency division. The slope of the lR high/lowpass filter can be set, among which Bessel and Butterworth can be set to 12dB18dB,24dB,36dB,48dB per octave, Linkwitz-Riley can be set to 12dB, 24dB36dB,48dB per octave.
-
512-order FlR filtersupports three modes: high-pass, low-pass and band-passSix window types are optional
-
Each input/output has gain, delay, phase control and mute, the delay can beup to 1000ms, the delay unit can choose milliseconds (ms), meters (m), feet(ft)three, step size There are five options: x0.001,x0.01,x0.1, x1.0,x10.0
-
The output channel supports RMS pressure limit, the threshold range is -6dB~12dB, the compression ratio is 1:1-128:1, and the startup timeis 3ms-100ms
-
Support channel concatenation and channel replication, can select multiplechannel associations simultaneously to adiust parameters synchronously.
