SW-115B

Single 15" passive subwoofer system

SW-115B
SW-115B
SW-115B
SW-115B
SW-115B
SW-115B
SW-115B
SW-115B

15" large magnetic circuit ultra-low distortion woofer

  • Audio SW-115B is a compact 15" subwoofer speaker that delivers powerful ultra-low frequency response.


Main Features

  • Rated Power: 800W (AES)
  • Peak Power: 3200W (AES)
  • Input Connection: 2*NeutrikTM 2+2-
  • Sensitivity: 98dB
  • Maximum Sound Pressure Level: 132dB
  • Nominal Impedance: 8 Ohms
  • Net Weight: 36Kg
  • Enclosure Dimensions: 450mm*600mm*505mm (W*D*H)

Product Description

The Audio SW-115B is a compact 15" subwoofer that delivers powerful ultra-low frequency response. The woofer and wooden cabinet design provide tight and precise bass response, making it an ideal match for the LY-10. The unit features a long-throw design with high magnetic force, resulting in greater magnetic flux to improve efficiency. A 40mm-high 4" voice coil ensures a stroke under 26mm/PP continuous magnetic drive. The specialized pulp fiber cone ensures the rigidity and inertial displacement of the unit. The triple heat-resistant copper flat wire reduces power compression caused by voice coil heating, comprehensively improving sound quality and performance.

Technical Specifications


Type: 15" Ultra-Low Frequency Multi-Purpose Speaker System
Frequency Response: 40Hz–300kHz
Power: 800W
Peak Power: 3200W
Impedance:
Dispersion Angle: --
Sensitivity: 98dB
Maximum SPL: 132dB
Crossover Point: External Crossover
Input Connector: 2*NeutrikTM 2+2-
Low Frequency: 15" woofer component with European imported custom bass driver, 4" (100mm) voice coil, rated power: 700W (AES)
High Frequency: --
Cabinet Material: 15mm marine-grade birch plywood
Cabinet Finish: Black polyurea paint
Net Weight: 36kg
Dimensions: 450mm × 600mm × 505mm (W × D × H)
