S5

Dual 5" coaxial loundspeaker

S5
S5
S5
S5
S5
S5
S5
S5

Two-way coherent point source coaxial system

  • The Audio S5 is suitable for various types of group activities or exhibition venue sound reinforcement, DJ monitoring, small entertainment venue sound reinforcement, or as a stage monitor.


Main Features

  • Rated Power: 300W (AES)
  • Peak Power: 1200W (AES)
  • Input Connection: 2*NeutrikTM NL4MP 1+1-
  • Sensitivity: 94dB
  • Maximum Sound Pressure Level: 124dB
  • Nominal Impedance: 8 Ohms
  • Dispersion: 100° conical
  • Net Weight: 6.0Kg
  • Dimensions: 155mm*350mm*205mm (W*H*D)

Product Description

The S5 is suitable for various types of collective activities or exhibition venue sound reinforcement, DJ monitoring, small entertainment venue amplification, stage monitoring, or as front-fill for live performances. In theaters, it is ideal for under-balcony fill.
The high-frequency driver of the S5 incorporates an ultra-light 1.75-inch annular diaphragm, delivering exceptional transient response with extremely high efficiency across the frequency range of 1 kHz to 20 kHz. This innovative transducer design provides coherent 100° wavefront radiation from a point source, ensuring excellent coverage control and clear, transparent high-fidelity sound. Additionally, it guarantees perfectly time-aligned, uniform sound coverage in coordination with other components.

Technical Specifications


Type: 2-way Full-range Multi-purpose Coaxial Loudspeaker System
Frequency Response: 80Hz–20kHz
Power: 300W
Peak Power: 1200W
Impedance:
Dispersion Angle: 100° conical
Sensitivity: 94dB
Maximum SPL: 124dB
Crossover Frequency: 1.5kHz (built-in crossover)
Input Connector: 2*NeutrikTM NL4MP 1+1-
Low-frequency Driver: 5"*2 aerospace-grade ferrite woofer, 1.5" (38mm) voice coil, rated power: 300W (AES)
High-frequency Driver: 1" throat, aerospace-grade ferrite compression driver, 1.75" (44mm) voice coil, rated power: 80W (AES)
Enclosure Material: 12+15mm Russian birch plywood
Enclosure Finish: Black polyurea paint
Net Weight: 6.0kg
Dimensions: 155mm*350mm*205mm (W*H*D)
