S8

Dual 8" coaxial loundspeaker

S8
S8
S8
S8
S8
S8
S8
S8

Two-way coherent point source coaxial system

  • The Audio S8 is suitable for various types of group activities or exhibition venue sound reinforcement, DJ monitoring, small entertainment venue sound reinforcement, or as a stage monitor.


Main Features

  • Rated Power: 450W (AES)
  • Peak Power: 1800W (AES)
  • Input Connectors: 2×NeutrikTM NL4MP 1+1-
  • Sensitivity: 98dB
  • Maximum SPL: 124dB
  • Nominal Impedance: 8Ω
  • Dispersion: 100° conical
  • Net Weight: 12.0kg
  • Dimensions (W×H×D): 230mm×540mm×270mm

Product Description

The S8 is suitable for various types of collective activities or exhibition venue sound reinforcement, DJ monitoring, small entertainment venue sound reinforcement, stage monitoring, or as front-fill for live performances. In theaters, it is ideal for under-balcony fill.
The high-frequency driver of the S8 features an ultra-light 1.75-inch annular diaphragm, delivering exceptionally efficient transient response across the frequency range of 1kHz to 20kHz. This innovative transducer design produces a coherent 100° wavefront radiation from a point source, offering excellent coverage control and clear, transparent high-fidelity sound. Additionally, it ensures perfect time-aligned integration with other components for uniform sound coverage.

Technical Specifications


Type: Two-Way Full-Range Multi-Purpose Coaxial Speaker System
Frequency Response: 60Hz-20kHz
Power: 450W
Peak Power: 1800W
Impedance:
Dispersion Angle: 100° Conical
Sensitivity: 94dB
Maximum SPL: 124dB
Crossover Point: 1.5kHz (Built-in Crossover)
Input Connector: 2*NeutrikTM NL4MP 1+1-
Low-Frequency Driver: 8"*2 Woofer with Aerospace-Grade Ferrite Low-Frequency Unit, 2" (51mm) Voice Coil, Rated Power: 450W (AES)
High-Frequency Driver: 1" Throat, European-Original Compression Driver, 1.75" (44mm) Voice Coil, Rated Power: 80W (AES)
Enclosure Material: 12+15mm Russian Birch Plywood
Enclosure Finish: Black Polyurea Paint
Net Weight: 12.0Kg
Dimensions: 230mm*540mm*270mm (W*H*D)
