D-208

Dual 8" full-range linearray loundspeaker

D-208
D-208
D-208
D-208
D-208

8" high-power, ultra-low distortion woofer

  • The Audio D-208 speaker features two built-in 8" 50mm voice coil, high-power, ultra-low distortion neodymium magnet woofers and a 120°x12° flat rectangular ABS horn with a 1" throat and a 38mm voice coil compression driver. Both the high and low-frequency units are custom-made imports from Europe, offering flexible use with professional hanging accessories. It is a 2-way multi-purpose full-range speaker system.


Main Features

  • Type: LF/2×8〞 + HF/2×1" throat
  • Frequency Response: LF/68Hz–4000Hz, HF/2000Hz–20000Hz
  • Power (AES): LF/200W (AES)/pc, HF/50W (AES)/pc
  • Impedance: 16Ω
  • Dispersion: 120°×12°
  • Maximum SPL: 135dB
  • Sensitivity: LF/98dB (1W&1M), HF/106dB (1W&1M)
  • Weight: 19.6kg
  • Dimensions: 640mm×249mm×332.5mm (W×H×D)

Product Description

The Audio D-208 speaker features two built-in 8" 50mm voice coil, high-power, ultra-low distortion neodymium magnet woofers and a 120°x12° flat rectangular ABS horn with a 1" throat and a 38mm voice coil compression driver. Both the high and low frequencies utilize custom-made, European-original imported components. With flexible professional hanging accessories, it is a 2-way versatile full-range speaker system. As a 2-way system, the D-208 can be driven directly or paired with a bi-amplifier system for superior high output. The Audio D-208 is suitable for stadiums, auditoriums, hotel conferences, theaters, large-scale events, and more, providing a powerful audio solution.

Technical Specifications


Type: LF/2×8〞 + HF/2×1" throat
Frequency Response: LF/68Hz–4000Hz, HF/2000Hz–20000Hz
Power: LF/200W (AES) per unit, HF/50W (AES) per unit
Impedance: 16Ω
Dispersion Angle: 120° × 12°
Sensitivity: LF/98dB (1W & 1M), HF/106dB (1W & 1M)
Maximum SPL: 135dB
Crossover Point: External crossover
Input Connector: 10-pin waterproof professional plug
Enclosure Connection Components: Aluminum profile 208
Enclosure Material: 15mm marine-grade birch plywood
Enclosure Surface Finish: Black polyurea paint
Speaker Mounting Hardware: D-208 compatible accessories
Line Array Pin Components: Φ10mm × 25mm
Enclosure Cover Plate: Black oxidized fine-textured finish
Net Weight: 19.6kg
Dimensions: 640mm × 249mm × 332.5mm(W × D × H)
