D-115C

Single 15" linearray low-frequency loundspeaker

D-115C
D-115C
D-115C
D-115C
D-115C
D-115C
D-115C

15" high-power ultra-low distortion woofer

  • The Audio D-115C features a built-in 15-inch, 100mm voice coil, high-power ultra-low distortion woofer. The bass unit is a custom-made European import, designed for flexible use with professional hanging accessories, making it a versatile subwoofer system.


Main Features

  • Type: LF/1×15〞
  • Frequency Response: LF/40Hz–300Hz
  • Power (AES): LF/600W (AES)/unit
  • Impedance: 8Ω
  • Dispersion Angle: --
  • Maximum SPL: 136dB
  • Sensitivity: LF/98dB (1W&1M)
  • Weight: 53.2kg
  • Enclosure Dimensions: 870mm×455mm×550mm (W×H×D)

Product Description

The Audio D-115C features a built-in 15", 100mm voice coil, high-power, ultra-low distortion woofer, with the bass unit being a custom-made European import. It boasts flexible professional hanging accessories and is a versatile subwoofer speaker system. As a single-way system, the D-115C can be driven directly or paired with a bi-amplified system to achieve higher output performance. It is designed to be used in conjunction with the D-208. The Audio D-115C is suitable for stadiums, auditoriums, mobile performances, theaters, large-scale events, and more, providing a powerful solution for audio systems.

Technical Specifications


Type: LF/1*15
Frequency Response: LF/40Hz-300Hz
Power: LF/600W (AES) per unit
Impedance:
Dispersion: --
Sensitivity: LF/98dB (1W & 1M)
Maximum SPL: 136dB
Crossover Point: External crossover
Input Connector: 10-pin waterproof professional connector
Enclosure Connection Components: Aluminum profile
Enclosure Material: 15mm marine-grade birch plywood
Enclosure Finish: Black polyurea paint
Speaker Mounting Hardware: D-115C compatible accessories
Line Array Pin Components: Φ10mm*50mm
Enclosure Cover: Black polyurea paint
Net Weight: 53.2Kg
Dimensions: 870mm*455mm*550mm (W*H*D)
