D-112B

Single 12" linearray low-frequency loundspeaker

D-112B
D-112B
D-112B
D-112B

12" high-power ultra-low distortion woofer

  • The Audio D-112B is a multi-purpose subwoofer speaker system equipped with a built-in 12-inch, 100mm voice coil, high-power, ultra-low distortion woofer. The bass unit is a custom-made European import, designed for professional use with flexible hanging accessories.


Main Features

  • Type: LF/1×12〞
  • Frequency Response: LF/40Hz–300Hz
  • Power (AES): LF/500W (AES) per unit
  • Impedance: 8Ω
  • Dispersion Angle: --
  • Maximum SPL: 130dB
  • Sensitivity: LF/98dB (1W&1M)
  • Weight: 40kg
  • Enclosure Dimensions: 640mm × 436mm × 595mm (W × H × D)

Product Description

The Audio D-112B features a built-in 12-inch, 100mm voice coil, high-power, ultra-low distortion woofer. The bass unit is a custom-made European import, offering flexible professional hanging accessories, making it a versatile subwoofer speaker system. As a single-way system, the D-112B can be driven directly or paired with a bi-amplified system for superior high output. Designed to complement the D-208, the Audio D-112B is suitable for gymnasiums, auditoriums, mobile performances, theaters, large-scale events, and more, providing a powerful solution for audio systems.

Technical Specifications


Type: LF/1*12
Frequency Response: LF/40Hz-300Hz
Power: LF/500W (AES)/unit
Impedance:
Dispersion Angle: --
Sensitivity: LF/98dB (1W&1M)
Maximum SPL: 130dB
Crossover Point: External crossover
Input Connector: 10-pin waterproof professional connector
Enclosure Connection Components: Aluminum profile
Enclosure Material: 15mm marine-grade birch plywood
Enclosure Surface Finish: Black polyurea paint
Speaker Hanging Hardware: D-112B matching accessories
Line Array Pin Components: Φ10mm*50mm
Enclosure Cover: Black polyurea paint
Net Weight: 40Kg
Dimensions: 640mm*436mm*595mm (W*H*D)
